Low-e Glass

LOW-E GLASS

Low-E (Low Emissivity) glass is a high-performance insulating glass designed to improve energy efficiency. It features a microscopic metal oxide coating on the glass surface that helps control solar heat gain and blocks harmful UV rays.



Low-E glass is an environmentally friendly building material.
In addition to providing energy efficiency, it helps reduce carbon emissions and supports zero-emission goals. It is an essential choice for sustainable and green building projects.



TECHNICAL SPECIFICATIONS

Thickness Options:

• Monolithic Low-E Glass: 4 mm, 5 mm, 6 mm

• Double Glazing Units: 4+12+4 mm, 6+12+6 mm, 4+16+4 mm

• Laminated Low-E Glass: 3.3.1 mm, 4.4.2 mm, 5.5.2 mm (optional)

Sizing and Dimensions:

• Maximum Size: 2400 mm x 5000 mm (custom sizes available upon request)

• Minimum Size: 200 mm x 300 mm

• Tolerance: ±2 mm

• Cutting: CNC precision cutting, custom sizing possible

Edge Finishing:

• Straight cut (standard)

• Polished edge

• Beveled edge (custom)

• Ground edge (safe for manual handling)

Tempering:

• Tempered Low-E glass option available

• Compliant with EN 12150 standard

• Shatters into small fragments to reduce injury risk

• Heat treatment applied prior to coating (especially for Soft-Coat)

Coating Types:

• Soft-Coat Low-E: High-performance, applied to the inner surface, used mainly in double glazing

• Hard-Coat Low-E: More durable, applied to outer surface, suitable for single-pane usage

Thermal and Light Performance (e.g., 4+12+4 mm unit):

• Thermal transmittance (U-Value): 1.1 – 1.4 W/m²K

• Solar factor (g-value): 0.48 – 0.62

• Light transmittance: 70% – 82%
  (Note: Values vary depending on glass combination and manufacturer)

Application Areas:

• Exterior glazing in residential buildings

• Office buildings and commercial spaces

• Storefronts and display windows

• Conservatories and glass balconies

• Green building projects focused on energy savings

Application Format:

• Usable as single-pane glass (Hard-Coat)

• Can be integrated into double or triple glazing units

• Can be laminated with PVB film for safety applications

Warranty:

• Coating warranty: 10 years

• Manufacturing defects: 2 years

• Warranty valid under proper installation, sealing, use, and maintenance
